2. Do not bundle input wiring with power wiring or any other high energy cables. 3. Wire sizes: 14 AWG (2.088 mm2) max., 22 AWG (0.322 mm2) min. Dry Contact relay outputs: 1.Dry contact relays. 2.Relay contact rating (resistive load): Nominal switching capacity: 30 VDC/VAC, 1A 3.Max. combined output current per board = 4 Amps.. Refer to the wiring diagram provided by Mettler Toledo or the load cell manufacturer to ensure that the load cell is wired correctly. Make sure that the correct wires are connected to the corresponding terminals. 3. Test Continuity. Use a multimeter to test the continuity of the wiring connections. Check for any breaks or faults in the wires.
Up to 8 POWERCELL load cells. Analog Load Cell Excitation Voltage . 5 VDC. Automation interface Update Rate . IND360 analog: 960 Hz IND360 POWERCELL: 100Hz for 1~4 LCs; 50 for 4~8 LCs . IND360 Precision: 92 Hz . Display DIN . Rail mount version: 1.04'' green OLED Panel mount version: 4.3'' color TFT . Harsh version: 4.3'' color TFT : Keypad. 10 METTLER TOLEDO Installation Manual POWERCELL® PDX® Load Cell Order number 61044072 01/11 Components Receiver Variant 2 "Retrofit" The "retrofit" receivers are designed to make POWERCELL PDX load cells compatible with scales that are built for use with POWERCELL 760 or MTX load cells (designs using a 69.85-mm-diameter hole).
